Broan® AI Series 180 CFM Heat Recovery Ventilator (ERV)

From the leader in residential indoor air quality this Broan® AI Series ERV features VIRTUO™ technology providing the easiest installation on the market. This fresh air system has the quickest installation in its category saving the installer up to 20 minutes, thanks to auto-balancing and self-adjusting technology. The built-in LCD screen provides real-time airflows, power consumption and acts as a diagnostic error tool. This technology not only eliminates the most complex part of installation, saving the contractor time but it also significantly reduces the number of call-backs. This product delivers consistent results with airflow verification providing the most efficient and reliable solution on the market regardless of dwelling type. Delivering 180 CFM our powerful, efficient and proprietary blower fan motors make it the ideal solution for larger homes. Installing an Energy Recovery Ventilator (ERV) improves the indoor air quality of your home by providing a supply of tempered, filtered outdoor fresh air while exhausting the stale polluted air from your home, leaving the air healthier and more comfortable. The standard MERV 8 filter offers a more effective design than units in the market with larger capture area and will save the homeowner money with the reusable, easy to wash design. At Broan-NuTone we believe that better quality of air means better quality of life.

The industry’s most advanced residential fresh air system, created to offer a universal platform specifically designed and improved to make life easier while delivering constant superior air quality.

• Thanks to the VIRTUOTM™ technology, the airflow calibration and auto-balancing are achieved quickly and maintained throughout the life of the product
• Select the desired CFM using the proven integrated LCD screen
• Integrated electronic airflow measurement device with real time LCD
• Integrated diagnostic tool
• Equipped with PMSM ECM motors for energy efficient operation
• Suspended installation (chains included)
  OR
• Wall-mount installation (universal brackets included)
  • installation with 2 brackets
  • installation with 4 brackets

Unit Description

• SRE of 78% at 32°F (81 CFM) and 64% at -13°F (83 CFM) and SRE of 81% at 32°F (66 CFM)
• Ports size: 6″
• Recirculation defrost
• Corrosion resistant galvanized steel door and cabinet
• One-piece molded insulation shell, no air leakage (expanded polystyrene; UL 94 HF-1 certified)
• VIRTUOTM constant airflow and auto-balancing device(patent pending)
• Motorized dampers (no additional backdraft dampers required)
• Recirculate air within the dwelling with recirculation mode using a main wall control
• 6′ power cord
• Unit electrical characteristics:
  120 volts, 60 Hz, 3 A, 200 W
• For residential indoor installation only

Core

• Polypropylene crossflow core with polymeric membrane and aluminum covers, impact resistant, non washable

Filters

• MERV 8 grade washable standard filter (included)
• Optional MERV 13 grade filter part no. V24300

Options

• Indoor and outdoor terminations
